Gas cylinder pictogram (GHS04)
The gas cylinder pictogram (GHS04) is assigned to two hazard classes in UN GHS Rev.11: gases under pressure and chemicals under pressure. Of the five class and category rows below, one takes Danger and four take Warning. They call for five hazard statements (H280, H281, H282 and others). OSHA's Figure C.1 lists it for gases under pressure and chemicals under pressure, and EU CLP Annex V gives it one entry. Under EU CLP it is optional when the flame or the skull and crossbones applies (Article 26(1)(e)).
Hazard classes and categories (UN GHS Rev.11)
| Hazard class | Category | Signal word | Hazard statements |
|---|---|---|---|
| Gases under pressure (ch. 2.5) | Compressed gas, liquefied gas, dissolved gas | Warning | |
| Gases under pressure (ch. 2.5) | Refrigerated liquefied gas | Warning | |
| Chemicals under pressure (ch. 2.3.2) | Category 1 Flame and gas cylinder | Danger | |
| Chemicals under pressure (ch. 2.3.2) | Category 2 Flame and gas cylinder | Warning | |
| Chemicals under pressure (ch. 2.3.2) | Category 3 | Warning |
Symbol, signal word and hazard statements from UN GHS Rev.11, Annex 3 section 3.
By jurisdiction
US OSHA HCS
- Gases under pressure
- Chemicals under pressure
EU CLP
- Gases under pressure: compressed, liquefied, refrigerated liquefied and dissolved gases (2.5)
Under Article 26(1)(e), if GHS02 or GHS06 applies, GHS04 is optional.
Canada WHMIS (HPR)
Schedule 3, item 5: Gas cylinder. Used for each HPR category (Parts 7 and 8) that GHS Rev.7 Annex 3, section 3 assigns this symbol to (s. 3(1)(c)), with the Schedule 3 pictogram in place of the symbol (s. 3(3)). Schedule 5 covers only the HPR-specific classes (s. 3(1)(d)). For chemicals under pressure the HPR uses GHS Rev.8 instead (s. 3(1)(c.1), (c.2)).
Mexico NOM-018-STPS-2015
Spanish name in NOM-018 Appendix B: “Botella de gas”. Table B.3 lists the categories that take it.
Precedence rules that involve GHS04
UN GHS Rev.11, 1.4.10.5.3.1
- For substances and mixtures covered by the UN Model Regulations, precedence of symbols for physical hazards follows the Model Regulations. In workplace settings the competent authority may require all physical hazard symbols.
EU CLP, Article 26(1)
- (e) If GHS02 or GHS06 applies, GHS04 is optional.
Download
GHS04 EPS (vector) and PNG: copies of the US OSHA files, a US government work (licensing).
Sources: UN GHS Rev.11 Annex 3; 29 CFR 1910.1200 Appendix C; EU CLP Article 26 and Annex V; Canada HPR Schedules 3 and 5; NOM-018-STPS-2015 Appendix B. Sources and revision notes.
