Flame over circle pictogram (GHS03)
The flame over circle pictogram (GHS03) is assigned to three hazard classes in UN GHS Rev.11: oxidizing gases, oxidizing liquids and oxidizing solids. Of the seven class and category rows below, five take Danger and two take Warning. They call for three hazard statements (H270, H271 and H272). OSHA's Figure C.1 lists it for oxidizers, and EU CLP Annex V gives it three entries. Under EU CLP it becomes optional when the exploding bomb applies, unless more than one of those pictograms is compulsory (Article 26(1)(a)).
Hazard classes and categories (UN GHS Rev.11)
| Hazard class | Category | Signal word | Hazard statements |
|---|---|---|---|
| Oxidizing gases (ch. 2.4) | Category 1 | Danger | |
| Oxidizing liquids (ch. 2.13) | Category 1 | Danger | |
| Oxidizing liquids (ch. 2.13) | Category 2 | Danger | |
| Oxidizing liquids (ch. 2.13) | Category 3 | Warning | |
| Oxidizing solids (ch. 2.14) | Category 1 | Danger | |
| Oxidizing solids (ch. 2.14) | Category 2 | Danger | |
| Oxidizing solids (ch. 2.14) | Category 3 | Warning |
Symbol, signal word and hazard statements from UN GHS Rev.11, Annex 3 section 3.
By jurisdiction
US OSHA HCS
- Oxidizers
EU CLP
- Oxidising gases, category 1 (2.4)
- Oxidising liquids, categories 1, 2, 3 (2.13)
- Oxidising solids, categories 1, 2, 3 (2.14)
Canada WHMIS (HPR)
Schedule 3, item 2: Flame over circle. Used for each HPR category (Parts 7 and 8) that GHS Rev.7 Annex 3, section 3 assigns this symbol to (s. 3(1)(c)), with the Schedule 3 pictogram in place of the symbol (s. 3(3)). Schedule 5 covers only the HPR-specific classes (s. 3(1)(d)).
Mexico NOM-018-STPS-2015
Spanish name in NOM-018 Appendix B: “Llama sobre círculo”. Table B.3 lists the categories that take it.
Precedence rules that involve GHS03
UN GHS Rev.11, 1.4.10.5.3.1
- For substances and mixtures covered by the UN Model Regulations, precedence of symbols for physical hazards follows the Model Regulations. In workplace settings the competent authority may require all physical hazard symbols.
EU CLP, Article 26(1)
- (a) If GHS01 applies, GHS02 and GHS03 are optional, except where more than one of them is compulsory.
Download
GHS03 EPS (vector) and PNG: copies of the US OSHA files, a US government work (licensing).
Sources: UN GHS Rev.11 Annex 3; 29 CFR 1910.1200 Appendix C; EU CLP Article 26 and Annex V; Canada HPR Schedules 3 and 5; NOM-018-STPS-2015 Appendix B. Sources and revision notes.
