Corrosion pictogram (GHS05)
The corrosion pictogram (GHS05) is assigned to three hazard classes in UN GHS Rev.11: corrosive to metals, skin corrosion/irritation and serious eye damage/eye irritation. Of the three class and category rows below, two take Danger and one takes Warning. They call for three hazard statements (H290, H314 and H318). OSHA's Figure C.1 lists it for corrosives, and EU CLP Annex V gives it three entries. When it is on the label, the exclamation mark is not used for skin or eye irritation under the UN GHS, OSHA, EU CLP, Canada's HPR and NOM-018.
Hazard classes and categories (UN GHS Rev.11)
| Hazard class | Category | Signal word | Hazard statements |
|---|---|---|---|
| Corrosive to metals (ch. 2.16) | Category 1 | Warning | |
| Skin corrosion/irritation (ch. 3.2) | Category 1 and sub-categories 1A, 1B, 1C | Danger | |
| Serious eye damage/eye irritation (ch. 3.3) | Category 1 | Danger |
Symbol, signal word and hazard statements from UN GHS Rev.11, Annex 3 section 3.
By jurisdiction
US OSHA HCS
- Corrosives
EU CLP
- Corrosive to metals, category 1 (2.16)
- Skin corrosion, category 1 and sub-categories 1A, 1B, 1C (3.2)
- Serious eye damage, category 1 (3.3)
Under Article 26(1)(c), if GHS05 applies, GHS07 shall not appear for skin or eye irritation.
Canada WHMIS (HPR)
Schedule 3, item 4: Corrosion. Used for each HPR category (Parts 7 and 8) that GHS Rev.7 Annex 3, section 3 assigns this symbol to (s. 3(1)(c)), with the Schedule 3 pictogram in place of the symbol (s. 3(3)). Schedule 5 covers only the HPR-specific classes (s. 3(1)(d)).
Mexico NOM-018-STPS-2015
Spanish name in NOM-018 Appendix B: “Corrosión”. Table B.3 lists the categories that take it.
Precedence rules that involve GHS05
UN GHS Rev.11, 1.4.10.5.3.1
- If the corrosive symbol applies, the exclamation mark should not appear where it is used for skin or eye irritation.
US OSHA, Appendix C, C.2.1 and C.2.3.4
- If the corrosive pictogram is included, the exclamation mark shall not appear where it is used for skin or eye irritation.
EU CLP, Article 26(1)
- (c) If GHS05 applies, GHS07 shall not appear for skin or eye irritation.
Canada HPR, s. 3.6(3)
- If the corrosion symbol is required, the exclamation mark for skin or eye irritation does not apply.
Mexico NOM-018-STPS-2015, 10.6
- The exclamation mark is not used for health hazards when the skull and crossbones is used; when corrosion is used for skin or eye irritation; or for respiratory sensitization, even if the product is also a skin sensitizer or skin or eye irritant (as worded in 10.6).
Download
GHS05 EPS (vector) and PNG: copies of the US OSHA files, a US government work (licensing).
Sources: UN GHS Rev.11 Annex 3; 29 CFR 1910.1200 Appendix C; EU CLP Article 26 and Annex V; Canada HPR Schedules 3 and 5; NOM-018-STPS-2015 Appendix B. Sources and revision notes.
